TCT saw blade, the material body is 50# and OKE017 tip, carbide Tip: YG8, YGB, Teeth type is ATB teeth, Flat teeth, TCG. Application is cutting all kinds of soft, hard wood, non- Iaminated panels and plywood. Teeth number is 24T, 30T, 36T, 40T, 80T, 100T, 120T.

TCT saw blade 230mm x40T for wood
Promotion Restriction:	Not eligible for promotion for promotion
Arbor Hole size:	1inch
Abrasive Wheel Diameter:	9", 230mm
Series:	Wood
Ideally Used With:	Circular saw
Item:	230mmx 40T, 9"x40T
Packing:	10pcs each white inner box, 40pcs each colorful carton
Mini order:	1 carton each style, OME is 1000pcs each size each teeth

Choice of tooth profile

Commonly used tooth shapes include left and right teeth (alternating teeth), flat teeth, ladder flat teeth (high and low teeth), inverted trapezoidal teeth (inverted cone teeth), dovetail teeth (hump teeth), and rare industrial grade three Left and right, left and right flat teeth, etc.

1. The left and right teeth are the most widely used, the cutting speed is fast, and the grinding is relatively simple. It is suitable for cutting and cross sawing various soft and hard solid wood profiles and density boards, multilayer boards, particle boards, etc. The left and right teeth equipped with anti-repulsion protection teeth are dovetail teeth, which are suitable for longitudinal cutting of various boards with tree nodes; the left and right tooth saw blades with negative rake angle are usually used for pasting because of their sharp teeth and good cutting quality. Sawing of panels. anti kickback or right and left.

2. The flat tooth saw blade is rough, the cutting speed is slow, and the grinding is the simplest. It is mainly used for sawing of ordinary wood, with low cost. It is mostly used for aluminum saw blades with a small diameter to reduce adhesion during cutting, or for grooving saw blades to keep the bottom of the groove flat.

3. Ladder flat teeth are a combination of trapezoidal teeth and flat teeth. The grinding is more complicated. It can reduce veneer cracking during sawing. It is suitable for sawing of various single and double veneer wood-based panels and fireproof boards. In order to prevent adhesion, saw blades for aluminum use more saw blades with flat teeth.

4. The inverted ladder teeth are often used in the bottom groove saw blade of the panel saw. When sawing the double-faced wood-based panel, the groove saw adjusts the thickness to complete the grooving of the bottom surface, and then the main saw completes the sawing of the board. Prevent edge chipping in the saw edge.
